Ilova stsenariylari
Ushbu santrifüj yog 'tozalash mashinasi asosan turbinali yog'ni tozalash uchun ishlatiladi, bu yog'dagi namlik, gaz va aralashmalarni tez va samarali tarzda olib tashlashi mumkin. Yog 'sifatini yaxshilash, jihozni sozlash va moylash tizimining normal ishlashini ta'minlash va jihozga texnik xizmat ko'rsatish muddatini uzaytirish.
Mahsulot afzalliklari:
1. Suvni olib tashlash va emulsifikatsiyani buzish uchun kuchli qobiliyat, yog'da ko'p miqdorda suvni ajratish oson, shuningdek, yog'da oz miqdorda suvni olib tashlash ham oson. Yog 'tiniq va shaffof bo'ladi.
2. The ability to filter impurities is strong. The automatic backwashing filter bag can remove a large amount of impurities in the oil. The large area and deep precision filter material can remove the fine particles in the oil. It can be used instead of the oil system cleaning device to make the oil with serious pollution. The system can also be restored to within the "Operating Turbine Oil Pollution Control Standards".
3. Avtomatlashtirishning yuqori darajasi, kichik va engil, xavfsiz va ishonchli. Ushbu mashina infraqizil suyuqlik darajasidagi avtomatik boshqaruv moslamasini qabul qiladi, bu esa odam{1}}mashinani ajratishni amalga oshiradi va operatsiyani sodda va ishonchli qiladi.
Asosiy ishlash:
Santrifüj yog 'tozalash mashinasi taxminan 30 foiz suv miqdori, jiddiy emulsifikatsiyasi va NAS1636 15-sinfning ifloslanish darajasi bilan yog'ni tozalash uchun ishlatilishi mumkin. Ushbu mashinani aylanma tozalashdan so'ng, u quyidagilarga erishishi mumkin:
Tashqi ko'rinishi: iflosliklar yo'q, shaffof, erkin suv yo'q
Qoldiq namlik 50ppm dan kam
Filtrlashning aniqligi 5 mikrondan kam
Tozalik NAS1638, 5-daraja
Texnik parametr
Element | birlik | ZJC-10 | ZJC-20 | ZJC-30 | ZJC-50 | ZJC-75 | ZJC-100 | ZJC-150 | ZJC-200 | ZJC-300 |
Oqim darajasi | L/H | 600 | 1200 | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 | 18000 |
Vakuum darajasi | Mpa | -0.06 - -0.096 | ||||||||
Ish bosimi | Mpa | 0 dan kichik yoki unga teng.3 | ||||||||
Xatosiz | H | 4000 dan katta yoki unga teng | ||||||||
Doimiy ish vaqti | H | 150 dan katta yoki teng | ||||||||
Ishlash harorati | daraja | 40 - 70 | ||||||||
Isitish quvvati | kVt | 9 | 18 | 30 | 36 | 60 | 72 | 108 | 144 | 144 |
Umumiy quvvat | kVt | 11.5 | 17.5 | 33 | 39.5 | 66 | 79 | 115 | 153.5 | 154 |
Davolanishdan keyin neft indeksi | ||||||||||
Suv tarkibi | 80 ppm | |||||||||
Gaz tarkibi | 0.1 foizdan kam yoki unga teng | |||||||||
tozalik | Less than or equal to 5µm（or as per requirement） | |||||||||
Demulsifikatsiya qiymati | 10 daqiqadan kam yoki unga teng | |||||||||
Foydalanish bo'yicha ko'rsatmalar
Operation Precautions When the vacuum pump is working, pay attention to the oil condition displayed by the oil mark of the vacuum pump (the oil should be on the oil mark line). If it is found that there is too much water in the vacuum pump oil or it is too dirty, it should be replaced in time to avoid affecting the use of the vacuum pump. life. (1# vacuum pump oil) When it is found that there is a lot of water in the cooler during operation, it should be released in time. Always pay attention to the change of the pressure gauge value. During the normal oil filtering process, if the pressure is found to be >0.3Mpa, filtrni tozalash yoki filtr elementini vaqtida almashtirish kerak.
